5.Invter infinitely adjustable speed control is realized, frozen goods freeze time is adjustable, it can be applied to processing of frozen goods.
FSW150 IQF TUNNEL FREEZER TECHNICAL PARAMETERS
Item | FSW150（ strawberry Frozen） | |
Product | straw berry | |
Capacity | 100-150kg/h | |
In/Out Temp. | +15℃ to -18℃ | |
Freezer Temp. | -35t o -40℃ | |
In/Out Time | 8-40min | |
Refrigerant | R404A | |
Consumption | 20.7kw | |
Freezing Container Thickness | 150mm | |
Product Height | ≤100mm | |
Belt Width | 1300mm | |
Product Input Conveyor/Output Conveyor | 600 mm | |
Water Input Pressure | ≥3 kg/cm2 | |
Freezer Power | 3.35 KW | |
In/out Guard Length | 600/600 mm | |
Freezer Size（L*W*H） | 8000×1800×2300mm | |
Freezer Body Material | Duplex stainless steel polyurethane insulation board density or 40 kg/m3, the thickness of 150 mm, 304 stainless steel outer plate thickness more than 0.8 mm | |
Main Electric Brand | Schneider(France) | |
Belt and Speed | Food-grade stainless mesh belt; Frequency conversion step less speed regulation | |
Slide Track Material | Ultrahigh molecular polyethylene material. | |
Internal Structure | All made of 304 Stainless Steel Material, Argon arc welding | |
Evaporator | Effective from large aluminum finned tube set, stainless steel panel stent | |
Fan and Motor | Aluminum alloy stainless steel duct fan low noise and waterproof electric power consumption | |
