Freeze Dryer Machine for Fruits And Vagetable Freeze Dry

1. Freeze-drying machine for vegetables: carrots, rapeseed, mushrooms, scallions, garlic, green beans, corn, spinach, etc. 2. Freeze-drying machine for meat: beef, pork, chicken, etc. 3. Freeze-drying machine for seafood : shrimp, fish fillets, crab meat, etc.1. Freeze-drying machine for vegetables: carrots, rapeseed, mushrooms, scallions, garlic, green beans, corn, spinach, etc. 2. Freeze-drying machine for meat: beef, pork, chicken, etc. 3. Freeze-drying machine for seafood : shrimp, fish fillets, crab meat, etc.
Availability:
Quantity:
  • FDM
  • FST
  • FDM01

Structural standard

结构标准

Technical parameters

技术参数

Remark

备注

Infrastructure 基础设施

Effective area of shelves

搁板有效面积

10㎡


Largest Capturing amount of water condenser

捕水量

120Kg/批


Power supply

电源

3相380V/50Hz


Installed power

装机功率

33Kw

380V/50Hz

Cooling Water flow

冷却水

10T/Hr

<28℃

Main Structure

整机结构

整体式   4540*1400*2450


Weight

重量

3800Kg


Drying Oven 仓体

Oven Material

仓体材料

SUS304/ 6mm thick

SUS304/厚度6mm


Door lock

门锁方式

Handle Lock

手柄门锁


Door Open direction

开门方位

Right door

右开门


open angle

开启角度

>110度


Door material

仓门材料

SUS304


Oven shell material

仓体外包

SUS304/厚度1.5mm


Oven Shape and Size

仓体几何形状以及尺寸

Cylinder圆形体  Φ1200×1900(Φ1300×3280)


Frost-resistant glass

防冻玻璃

φ210、δ25~27


Observation window

仓体观察窗

On the left side of the bin body

安装于正面,仓体左侧各一个


Seal

密封

The door of the box uses special section of silicone rubber to ensure the vacuum seal

箱门口使用特殊截面硅橡胶紧密贴合,确保真空密封


T digital sensor

T型数字传感器

T type thermocouple

T型热电偶


Plate layer 板层

Board material

板层材质

SUS304


Shelf No.(PC)

板层数目(块)

11+1

The top layer is the temperature compensation board

Stainless steel tray

不锈钢托盘

395*395*30

66 set

Plate spacing

板层间距

70mm


Board size (L * w * h)

板层尺寸(长*宽*高)

1190*800*15*2


Minimum plate temperature

板层温度

- 45℃


Maximum plate temperature

板层温度

+70℃


Heating power

加热功率

8 Kw/380V/50Hz


shelf Protection fence

防护栏

prevent the tray beyond the shelf


Water catcher  捕水仓

Water storage material

捕水仓材料

SUS304


The shape and size of the trap

捕水仓形状以及尺寸

circular

圆形   ¢1200*900


coil material & shape

盘管材料

SUS304


Coil form

盘管形式

Circular coil

¢25圆形盘管


Coil water meter area

盘管捕水表面积

≥12㎡


Observation Window

观察窗

1set, installed on the side

1个,安装于侧面


Frost-resistant glass

防冻玻璃

Shanghai  Φ100、δ25~27


Condenser lowest temperature

冷凝器温度

-65℃


defrosting method

化霜方式

water injection + soak

喷淋+浸泡


T digital sensor

T型数字传感器

T-type thermocouple

T型热电偶


Refrigerating System 制冷机组

Compressor model and No.

压缩机型号及数量

Bitzer GermanyT25hp wo stage piston

德国比泽尔   25Hp   双级活塞

1sets

1台

Power consumption

机组功率

18.75 Kw


Refrigerant

制冷剂

R404


Oil separator

油分离器

Xinchang

新昌瑞仕普


Oil Filter

过滤器

ZHEJIANG  Refrigeration


Oil pressure differential controller油压差控制器

ZHEJIANG  Refrigeration


gas-liquid separator

气液分离器

ZHEJIANG  Refrigeration


Dehumidification drying filter

除湿干燥过滤器

ZHEJIANG  Refrigeration


Pressure gage

压力表

ZHEJIANG  Refrigeration


High/low voltage protection relay高/低压保护继电器

ZHEJIANG  Refrigeration


Air-cooled condenser

风冷式冷凝器

ZHEJIANG  Refrigeration


Corrugated Damping Pipe

波纹避震管

ZHEJIANG  Refrigeration


Refrigerating solenoid valve

制冷电磁阀

DG8


expansion valve

膨胀阀

NRF5HW100


Copper pipe

紫铜管

φ16、¢12、¢10


Refrigeration return pipe

制冷回管

φ38无缝钢管


Vacuum Pump 真空系统

Vacuum Pump model.and No.

真空泵型号及数量

Germany LEYBOLD  D40B 德国莱宝 2.2kw

2sets

2台

Roots vacuum pump model. And No.罗茨真空泵型号及数量

Germany LEYBOLD 德国莱宝  1.1KW

1sets

1台

corrugated pipe

波纹管

Φ76、¢108

Vacuum Pipe Shock Resistance

真空管道防振

Pump air flow

泵组排气量

150L/S


Power consumption

机组功率

5.5Kw


Butterfly valve

管道手动蝶阀

GI-63   GI-100


Vacuum solenoid valve

真空电磁阀

DDC-65

Automatic open or close with vacuum pump

随真空泵自动开启或关闭

Vacuum gauge

规  管

ZJ-54/¢15.5


Final vacuum

极限真空度

3Pa

No-load

空载

System leakage rate

系统漏率

0.005 Pa.m3/sec


Circulation system 循环系统

Pipe material

管道材料

SUS304不锈钢无缝管


Circulation pump

循环泵

Denmark Grundfos 丹麦格兰富    1.1KW

1sets

1台

Power consumption

机组功率

9.1Kw


Ball valve

管道球阀

    DG50

符合Q/IAKX002-97标准


Circulating fluid

循环流体采用

Multiple fluid

多元液


Heat exchanger

热交换器

SwedenALFA瑞典ALFA   LAVAL

1sets

1台

Heating rate

加热速率

>1℃/min


Heating method

加热方式

Electric heating tube

电加热管4Kw/根*2


Control

控制方式

Manual / automatic control

手动/自动控制


Heater size

加热器尺寸

Φ250×300


Condenser size

捕液器尺寸

¢300*500


Control system 控制系统

System Monitoring Software

系统监控软件

shanghai

1set

1套

Console cabinet

柜式操纵台

1100×400×600

Control, record

控制,记录

PLC process control

PLC程序控制

SIEMENS(西门子)CPU  226 CN AC/DC/继电器

1

Thermocouple extension module

热电偶扩展模块

SIEMENS(西门子) EM 231 CN 4路热电偶输入(4    TC)

5

Analog Input Module

模拟量输入模块

SIEMENS  EM 231 CN 模拟量输入模块 4 输入*12位  (4  AI)

1

HMI touch panel

HMI触摸屏

TAIWAN

台湾屏通


Constant current

恒流源

shanghai

1

Switching Power Supply

开关电源

24V/5V

Taiwan MW companies / 24V/5V

各一只

Thermocouple

热电偶

T-type

T型

20支

Vacuum gauge

真空规

ZJ-54D

2

AC contactor

交流接触器

Germany SCHNEIDER

德国施耐德


Air-break

空气断路器

Germany SCHNEIDER

德国施耐德


Electric wire电线

10㎡、6㎡、4m2、2m2、1m2
