China High Quality 200kg/h IQF Tunnel Freezer for IQF Avocadoes Processing

Tunnel freezer is widely used in frozen strips, cubes or grain foods, such as ice cream, shrimp, shrimp, sliced ​​fish, meat dumplings, meat and chicken sub this tunnel freezer more capacity ,operation more convenient ,save labor.
Availability:
Quantity:
  • FSW200
  • FST
  • FST-0201
Tunnel freezer product description
Tunnel  freezing machine is widely used in frozen strips, cubes or grain foods, such as ice cream, shrimp, shrimp, sliced fish, meat dumplings, meat and chicken sub.
With a two-speed motor, expanding the use of energy saving.
Depending on the frozen product into left and right cross-blasting fan, air mixing, and the top-blowing, the refrigeration, to achieve the best quality and efficiency
1.Simeple structure, easy operation and long life.
2.Library stainless steel plate using double sandwich polyurethane insulation board, good insulation properties, the inner member made of stainless steel SUS304, easy to clean, HACCP requirements.
3. The stainless steel mesh belt, smooth surfaces, easy to clean.
4. Use water cream to ensure hygiene.

5.Invter infinitely adjustable speed control is realized, frozen goods freeze time is adjustable, it can be applied to processing of frozen goods.

 FSW200 IQF TUNNEL FREEZER TECHNICAL PARAMETERS

Item

FSW200 avocadoes Frozen

Product

avocadoes

Capacity

200kg/h

In/Out Temp.

+15 to -18

Freezer Temp.

-35t o -40

In/Out Time

8-40min

Refrigerant

R404A

Consumption

35kw

Freezing Container Thickness

150mm

Product Height

≤100mm

Belt Width

1300mm

Product Input Conveyor/Output Conveyor

600 mm

Water Input Pressure

≥3 kg/cm2

Freezer Power

3.75 KW

In/out Guard Length

600/600 mm

Freezer Size(L*W*H)

10801800×2300mm

Freezer Body Material

Duplex stainless steel polyurethane insulation board density or 40 kg/m3, the thickness of 150 mm, 304 stainless steel outer plate thickness more than 0.8 mm

Main Electric Brand

Schneider(France)

Belt and Speed

Food-grade stainless mesh belt; Frequency conversion step less speed regulation

Slide Track Material

Ultrahigh molecular polyethylene material.

Internal Structure

All made of 304 Stainless Steel Material, Argon arc welding

Evaporator

Effective from large aluminum finned tube set, stainless steel panel stent

Fan and Motor

Aluminum alloy stainless steel duct fan low noise and waterproof electric power consumption

tunnel freezer drawing

tunnel freezer drawing
