High-Efficiency Industrial Tunnel Cooler | Food
Rapid Cooling Solution
Product Description
First Cold Chain provides a professional high-efficiency Tunnel Cooler designed for rapid and controllable cooling in industrial food production lines. This industrial Tunnel Cooler stably brings high-temperature food products down to safe storage temperature, perfectly supporting continuous large-scale food processing across various industries.
This Tunnel Cooler efficiently cools hot products from an initial temperature of 80℃ or 60℃ down to a fresh-keeping range of 0~4℃ or 5~10℃ in a short time. Featuring a professional tunnel structure, it ensures uniform and stable cooling performance, laying a solid foundation for subsequent food preservation, packaging and transportation.
Equipped with an optimized large heat exchange area and large-spacing evaporator design, the Tunnel Cooler delivers exceptional heat transfer efficiency. Matched with strong and stable airflow, it rapidly accelerates the cooling process, enabling products to reach the ideal fresh-keeping temperature quickly and evenly.
Such fast and consistent cooling significantly extends product shelf life, enhances packaging stability and transportation performance, and effectively mitigates quality issues such as condensation, deformation or spoilage caused by residual heat.
With reliable performance and high efficiency, this Tunnel Cooler is ideal for industrial automated production. It helps food processing enterprises improve production efficiency, guarantee product consistency and achieve standardized mass production.
Widely applied to rapid cooling of cooked food, prepared dishes, pasta, meat products, jams and other high-temperature food items, the Tunnel Cooler provides a safe and efficient cooling solution for the modern food processing industry. Currently, we have mature and verified practical cases for jam cooling with capacities of 1200kg/h, showcasing our expertise in handling high-viscosity liquid food products.
Key Advantages
Professional industrial Tunnel Cooler with high-efficiency heat exchange system
Rapid cooling from 80℃/60℃ to 0-4℃ or 5-10℃
Large-spacing evaporator for maximized heat exchange efficiency
Strong wind speed ensures fast, even cooling for all product types
Extends food shelf life and improves packaging & transportation performance
Ideal for industrial continuous food production lines
Stable structure, easy operation and low maintenance costs
Customizable cooling capacity to meet specific production needs
FYW1200 TUNNEL COOLER TECHNICAL PARAMETERS
Item | FYW1200（ cooling jam ） |
Product | cooling jam
|
Capacity | 1200kg/h |
In/Out Temp. | +60℃ to 0-4℃ |
Cooler Temp. | -10℃ |
In/Out Time | 10-50min |
Refrigerant | R507 |
Consumption | 100kw |
Freezing Container Thickness | 100mm |
Product Height | ≤100mm |
Belt Width | 1800mm |
Product Input /Output Conveyor | 1000/600 mm |
Water Input Pressure | ≥3 kg/cm2 |
Freezer Power | 7.5KW |
Freezer Size（L*W*H） | 15600×2300×2500mm |
Freezer Body Material | Duplex stainless steel polyurethane insulation board density or 40 kg/m3, the thickness of 100 mm, 304 stainless steel outer plate thickness more than 0.8 mm |
Main Electric Brand | Schneider(France) Siemens DLX etc |
Belt and Speed | Food-grade stainless steel mesh belt; Frequency conversion stepless speed regulation |
Slide Track Material | Ultrahigh molecular polyethylene material. |
Internal Structure | All made of 304 Stainless Steel Material, Argon arc welding |
Evaporator | Effective from large aluminum finned tube set, stainless steel panel stent |
Fan and Motor | Aluminum alloy stainless steel duct fan low noise and waterproof electric power consumption |
