Spiral freezer machine introduce：
Spiral freezer is a kind of high efficiency, energy saving quick-frozen device
Introducing our Spiral Freezer for Frozen Fish - a cutting-edge solution for quick and efficient freezing of fish. With its fully automated functionality, this machine is designed to save labor costs and streamline your freezing process.
Customization is at the core of our Spiral Freezer for Frozen Fish, allowing you to tailor the machine to meet your specific requirements. Whether it's the freezing temperature, freezing time, or any other parameter, we can customize it to ensure optimal results for your fish products.
Our Spiral Freezer for Frozen Fish has gained immense popularity worldwide, with satisfied customers from various countries. Its exceptional performance and reliability have earned us consistent praise from our clients.
As a reference, our Spiral Freezer for Frozen Fish currently boasts a production capacity of 600kg/h. This high output ensures that you can meet the demands of your customers efficiently and effectively.
Invest in our Spiral Freezer for Frozen Fish and experience the benefits of automated, fast freezing. Maximize your productivity, minimize labor costs, and deliver top-quality frozen fish products to your customers.
FSL600 SPIRAL FREEZER TECHNICAL PARAMETERS
Item | FSL600（fish） | |
Product | fish | |
Capacity | 600kg/h | |
In/Out Temp. | +15℃ to -18℃ | |
Cooler Temp. | -35℃ | |
In/Out Time | 15-75min | |
Refrigerant | R717 | |
Refrigeration capacity | 100kw | |
Freezer Body Thickness | 150mm | |
Product Height | ≤80mm | |
Belt Width | 500mm (effective 430mm) | |
Belt length | 150m | |
Belt layer number | 15layers | |
Drum diameter | 2000mm | |
Product Input /Output Conveyor | 1000/500 mm | |
Water Input Pressure | ≥3 kg/cm2 | |
Cooler Power | 15.7KW(380V50HZ) | |
Cooler Size（L*W*H） | 5700×3500×4300 （don’t include inter/out conveyor length） | |
Cooler Body Material | Duplex stainless steel polyurethane insulation board density or 40 kg/m3, the thickness of 150 mm, 304 stainless steel outer plate thickness more than 0.8 mm | |
Main Electric Brand | Schneider(France) | |
Belt and Speed | Food-grade stainless steel belt; Frequency conversion stepless speed regulation | |
Slide Track Material | Ultrahigh molecular polyethylene material. | |
Internal Structure | All made of 304 Stainless Steel Material, Argon arc welding | |
Evaporator | Effective from large aluminum finned tube set, stainless steel panel stent | |
Fan and Motor | Aluminum alloy stainless steel duct fan low noise and waterproof electric power consumption | |
